확장관 형상에 따른 유체유기진동기반 방사소음 특성에 관한 연구
- Alternative Title
- Study on the Characteristics of Radiated Sound with various shape of the Expanded Pipe based on the Fluid-Structure Interaction
- Abstract
- Flow characteristics inside an expanded cavity under high Reynolds number containing noise and vibration have recently been highlighted in connection with the strict regulation maintaining a comfortable environment. Noise and vibration phenomena occurring in a pipe is usually accompanied by a complex flow and structural interaction. Although it can be estimated in an even simple case of the expanded pipes having complex turbulent flow, the radiated noise caused by the size, shape and thickness of the given model propagates and makes serious interference effect and instability of the surrounding systems, and it finally gets a fatigue fracture and failure. Formulation of a coupled Fluid-Structure system can be expressed by the combination of Navier-Stokes equation governing flow structure inside a duct, elastic wave equation governing dynamic momentum motion and suitable boundary conditions. The flow interaction between surrounding bodies and small-scale flow eddies in a high speed turbulent flow is highly complicated to predict so that the fluid-structural interaction(FSI) analysis must be coaxially performed to ensure the reliability of the upcoming results. In this study, the user-defined FSI modules are developed by the combination of several commercial codes. They include 3 representative codes such as FLUENT known as the flow solver, NASTRAN as dynamic motion solver of complex structures and finally radiated noise solver - SYSNOISE - which is based on BEM(Boundary Element Method) scheme. The study undertakes the flow characteristics inside an expanded pipe and establishes some procedures analyzing the flow-induced vibration of body/surface and finally get a radiated noise from the vibration source. In the results, the expanded pipe having a resonator cavity with a bottle neck has the SPL(Sound Pressure Level) around -30dB, which is the lowest value among other four cavities.
- Author(s)
- 이영태
- Issued Date
- 2010
- Awarded Date
- 2010. 2
- Type
- Dissertation
- Keyword
- 유동유기진동(flow-induced vibration) 방사소음(radiated noise) 확장관(cavity) 맥동류 유동(pulsating flow) FSI(Fluid-Structure Interaction)
- Publisher
- 부경대학교
- URI
- https://repository.pknu.ac.kr:8443/handle/2021.oak/10271
http://pknu.dcollection.net/jsp/common/DcLoOrgPer.jsp?sItemId=000001956040
- Alternative Author(s)
- Lee, Young Tae
- Affiliation
- 부경대학교 대학원
- Department
- 대학원 기계공학부에너지시스템공학전공
- Advisor
- 임희창
- Table Of Contents
- 목 차
Abstract
Nomenclature
제 1 장 서 론 1
1.1 연구 배경 1
1.2 기존 연구 4
1.3 연구 목적 5
제 2 장 이론적 배경 7
2.1 소음해석의 이론적 배경 7
2.2 유동해석 지배방정식 9
2.3 구조진동해석 지배방정식 10
2.4 방사소음해석 지배방정식 13
제 3 장 수치해석기법 14
3.1 방사소음 범용 소프트웨어 14
3.2 연구방향 및 연구과정 도식화 16
3.3 유동해석 수치기법 및 경계조건 20
3.3.1 LES 수치해석기법 21
3.3.2 해석 모델 및 경계조건 22
3.3.3 유동해석 입구조건 24
3.4 구조진동해석 수치기법 및 경계조건 26
3.5 방사소음해석 수치기법 및 경계조건 28
제 4 장 유동해석 31
4.1 격자 의존성 검사 31
4.2 확장관 형상에 따른 유동특성 비교 34
4.3 비정상 유동 특성 37
4.4 맥동류 유동 특성 40
제 5 장 구조진동 해석 43
5.1 유동에 의한 구조진동해석 43
제 6 장 방사소음 해석 45
6.1 방사소음 특성 : 맥동류 입구조건이 아닐 경우 45
6.2 방사소음 특성 : 맥동류 입구조건이 적용된 경우 49
제 7 장 실제 머플러유동에의 응용 53
7.1 무향실 측정실험 53
7.2 수치해석에서의 입구조건 모델링 56
7.3 머플러 주위 방사소음 해석 결과 58
제 8 장 결 론 60
제 9 장 참고문헌 62
- Degree
- Master
-
