GTAW 용융효율 측정용 고성능 칼로리메터의 개발 및 그 응용
- Alternative Title
- Development and application of the high performance calorimeter to measure the melting efficiency of GTAW
- Abstract
- GTAW is very well-known and useful process in industry. Melting base metal with adequate penetration and bead width is important in welding. However low melting efficiency caused by long arc length or slow welding speed induce high heat input, so that excessive welding distortion is produced. Accurate information about heat conducted to the base metal from the melting efficiency measurement is necessary and should be considered for the setting of the welding condition. Therefore, in this study, a high performance calorimeter was developed to measure arc efficiency and the melting efficiency for arc efficiency. The method of calculating the arc energy that the machine output energy minus the short circuit energy was presented, and the method of calculating the arc efficiency that is the ratio of the heat into base metal to the arc energy was presented.
- Author(s)
- 조진안
- Issued Date
- 2007
- Awarded Date
- 2007. 2
- Type
- Dissertation
- Keyword
- 용융효율 GTAW Melting efficiency calorimeter GasTungsten ArcWelding
- Publisher
- 부경대학교 대학원
- URI
- https://repository.pknu.ac.kr:8443/handle/2021.oak/11511
http://pknu.dcollection.net/jsp/common/DcLoOrgPer.jsp?sItemId=000001953332
- Alternative Author(s)
- Cho, Jin-An
- Affiliation
- 부경대학교 대학원
- Department
- 대학원 소재프로세스공학과
- Advisor
- 조상명
- Table Of Contents
- 1. 서론 = 2
1.1 연구 배경 및 필요성 = 2
1.2 연구 목적 및 개요 = 2
2. 이론적 배경 = 3
2.1 GTAW process = 3
2.1.1 GTAW의 정의 = 4
2.1.2 GTAW의 원리 = 4
2.2 용접의 아크 물리학 = 5
2.2.1 용접의 아크특성 = 5
2.2.2 Ar 가스와 He 가스의 물리적 성질 = 9
2.2.3 실드가스에 따른 아크 에너지 분포 = 10
2.2.4 전극 형상에 따른 아크압력 분포특성 = 11
2.2.5 전기 회로에서의 에너지 손실 = 12
2.3 칼로리 측정 방법에 관한 연구 동향 = 13
2.3.1 칼로리 정의 = 13
2.3.2 칼로리 측정방법 = 13
2.4 용융효율 측정법에 대한 연구동향 = 17
2.4.1 용융효율 정의 = 17
2.4.2 용융효율 측정방법 = 19
3. 칼로리메터 개발 = 21
3.1 서언 = 21
3.2 칼로리메터 구성 = 21
3.2.1 유량 모니터링 시스템 캘리브레이션 = 22
3.2.2 온도 모니터링 시스템 캘리브레이션 = 24
3.2.3 칼로리메터 캘리브레이션 = 27
3.3 결언 = 34
4. 용접전류와 단락에너지 관계 검토 = 35
4.1 서언 = 35
4.2 실험방법 = 35
4.3 실험 결과 및 고찰 = 40
4.4 결언 = 42
5. 아크효율에 미치는 용접전류의 영향 검토 = 43
5.1 서언 = 43
5.2 실험방법 = 43
5.3 실험 결과 및 고찰 = 48
5.4 결언 = 53
6. 용융효율에 미치는 아크길이의 영향 검토 = 54
6.1 서언 = 54
6.2 실험방법 = 55
6.3 실험 결과 및 고찰 = 56
6.4 결언 = 60
7. 결론 = 61
참고 문헌 = 64
- Degree
- Master
-
Appears in Collections:
- 대학원 > 소재프로세스공학과
