Ultrasound Transducers by Using PVDF and PMN-PZT for Photoacoustic Imaging

Metadata Downloads
Abstract
Photoacoustic (PA) imaging is a new developing imaging modality which has a potential for application in various areas, such as biomedicine and medical diagnosis. This imaging technology is a hybrid modality which combines the high contrast of optical imaging and the high spatial resolution of ultrasound imaging. It is based on the photoacoustic effect of materials or biological tissues, and it uses ultrasound transducers to detected laser-generated ultrasound signals for imaging. In PA imaging systems, ultrasound transducer is a very important part. Various kinds of transducers have been applied in these systems. Most of them are single element, linear array or curved array transducers. Several researchers have used circular array transducers to obtain high resolution images of tissue of small animals. However, the receiving sensitivity of the transducers is still not high enough for detection of weak PA signals.
The aim of this study is to develop the effective ultrasound transducers with high sensitivity in the frequency range of 1~10 MHz which is commonly used for low frequency PA imaging. In this study, piezoelectric PVDF films have been used to make a plane single element transducers and a 120-element circular array transducer. Besides that, piezoelectric single crystal PMN-PZT has been used to make a needle point transducer (or called needle hydrophone) and a circular array transducer with 120 needle hydrophones.
The pulse-echo response characteristics of the transducers were measured and compared. The results show that the PVDF single element transducer has center frequency about has a center frequency about 10.1 MHz and -6 dB bandwidth about 9.2 MHz (MHz, 91.1% fractional bandwidth). The PVDF circular array transducer has a similar center frequency (11.3 MHz) as the single element transducer. But it has a narrow -6 dB bandwidth about 5.7 MHz (50.4% fractional bandwidth). The PMN-PZT single element and circular array transducer have same center frequency about 6.2 MHz with a -6 dB bandwidth about 5.6 MHz (90.3% fractional bandwidth).
The receiving sensitivities of the fabricated transducers were compared. The PMN-PZT transducer shows a higher receiving sensitivity (Vpp = 90 mV) than the PVDF transducer (Vpp = 50 mV). The variation of the relative receiving sensitivity of PMN-PZT array transducer is about ±1.5 dB. For PVDF array transducer, the relative receiving sensitivity changes in the range from -47.1 dB to -37.9 dB. The PMN-PZT array transducer shows much better uniformity than the PVDF array transducer.
The fabricated transducers were applied to PA imaging systems. The single element transducers were used in a PA imaging system based on scanning acoustic microscopy approach. By comparing the obtained PA signals and PA images, it could be found that the PMN-PZT hydrophone has high PA receiving sensitivity and could obtained PA images with higher contrast than PVDF transducers. The PMN-PZT circular-array transducer was used in a PA imaging system based on tomography approach. The PA images were obtained with high resolution. Besides that, the influence factors of PAT imaging were discussed.
From this study, it is found that the PMN-PZT hydrophone shows much higher receiving sensitivity than the PVDF transducer. It obtained the PA image with higher quality than PVDF transducer. And the circular array transducer made by 120 PMN-PZT hydrophones can obtain PA images with high contrast. It has the potential to make image with higher resolution.
