Two-phase inverter를 활용한 스마트워치의 무선충전 시스템
- Abstract
- Recently, development of wearable device as worn on the body small portable computing devices is being active. Accordingly, many wearable devices have been sold in market. Among the many types of wearable device, Smart Watch can worn on the wrist and can watch phone call, Email, sns and letter. and currently many users love this device. Smart watches are usually charged with wire cable, so I develop the smart watch that can wireless charging. Wireless Power Transfer (WPT) systems have been intensively researched. Wireless power transfer system help us, can use electrical equipment easily. because disappear power cable. However, pickup device’s relative position of transmission system affect the power transfer efficiency. In this paper, suggest multi-feeder coil system to solve this problem using the 2-phase inverter have a phase difference of 90 degrees. In this case, generated magnetic flux is without being affected by the angle of rotation.
In this paper, suggest how you can effectively charge to smart watch using wireless charging.
- Issued Date
- 2014
- Awarded Date
- 2014. 8
- Type
- Dissertation
- Publisher
- 부경대학교
- Affiliation
- 대학원
- Department
- 대학원 전자공학과
- Advisor
- 전성즙
- Table Of Contents
- 표 목 차 ................................................................................................................................ ⅱ
그 림 목 차 ........................................................................................................................... ⅱ
Ⅰ. 서 론 .............................................................................................................................. 1
1.1. 연구 배경 .................................................................................................................. 1
1.2. 연구 목적 및 필요성 ............................................................................................... 4
Ⅱ. 관련 이론 및 동작원리 ................................................................................................ 7
2.1. 무선전력전송의 기본 개념 ................................................................................... 7
2.2. 2-phase inverter의 동작원리 ............................................................................... 11
2.2.1. 기존 무선전력전송 방식의 한계 ................................................................... 11
2.2.2. 제안하는 새로운 방식 .................................................................................... 13
Ⅲ. 송신부 설계 .............................................................................................................. 17
3.1. 시스템 개요 ............................................................................................................. 17
3.2. Inverter 부 ............................................................................................................ 18
3.3. Isolation Transformer 부 .................................................................................... 25
3.4. Feeder 부 ................................................................................................................. 27
Ⅳ. 수신부 설계 .................................................................................................................. 29
4.1. 3-phase 수신부의 설계 .......................................................................................... 29
4.1.1. Single pickup coil ............................................................................................ 29
4.1.2. Multiple pickup coil ....................................................................................... 31
4.1.3. Simulation 결과 ................................................................................................ 34
4.2. 수신부의 공진과 정류 ............................................................................................ 37
4.2.1. 수신부의 공진 ................................................................................................... 37
4.2.2. 수신부의 정류 ................................................................................................... 40
Ⅴ. 실험 및 결과 .................................................................................................................. 44
Ⅵ. 결 론 ........................................................................................................................... 52
Ⅶ. 참고 문헌 ....................................................................................................................... 53
- Degree
- Master
- Files in This Item:
-
-
Download
Two-phase inverter를 활용한 스마트워치의 무선충전 시스템.pdf
기타 데이터 / 3.66 MB / Adobe PDF
-
