알루미늄 판재의 전기저항 마찰교반 스폿용접에 있어서 접합강도에 관한 연구
- Alternative Title
- A Study on Welding Strength of Electric Resistance Friction Stir Spot Welding using Aluminum Plates
- Abstract
- Vehicle weight reduction has become a recent issue of non-ferrous metals according to business efficiently for spot welding method capable of being accelerated studies. The electric resitance friction stir spot welding is efficiently welding method to two non-ferrous metals welding using the electric resistance heating with electric resistance heating. The aim of this paper is comprising the applicability of the electric resistance friction stir spot welding and design of the welding apparatus a few main factors influencing the weld strength and having optimum conditions. Thus, the electric resistance friction stir spot Welded specimens through Peel test and found the current conditions for welding, weld strength obtained through the tensile test on the basis of specific factors influence the strength and optimum welding conditions are found to have. As a result of 5052 aluminum having a thickness of 1.5mm and the electric resistance , friction stir spot welding when the energization time 90cycle, the tip diameter 10mm, the strength of current 7.6kA, the insertion depth of 0.8mm, a stirring speed of 400rpm stirring condition of the pin to the highest it was possible to obtain the weld strength , the size of the KS B ISO 18595 standard requires a minimum shear strength by about 152% could see the watering.
- Author(s)
- 장민수
- Issued Date
- 2014
- Awarded Date
- 2014. 8
- Type
- Dissertation
- Publisher
- 부경대학교
- URI
- https://repository.pknu.ac.kr:8443/handle/2021.oak/12436
http://pknu.dcollection.net/jsp/common/DcLoOrgPer.jsp?sItemId=000001967301
- Affiliation
- 기계공학과 대학원
- Department
- 대학원 기계공학과
- Advisor
- 진인태
- Table Of Contents
- 제 1 장 서 론 1
1.1 연구 배경 1
1.2 연구 목적 3
1.3 논문의 구성 8
제 2 장 전기저항 마찰교반 스폿용접 9
2.1 전기저항 마찰교반 스폿용접의 특징 9
2.2 전기저항 마찰교반 스폿용접의 가열 특징 11
2.2.1 마찰교반 점용접의 발열량 11
2.2.2 전기저항 점용접의 발열량 13
2.2.3 전기저항 마찰교반점용접의 발열량 15
제 3 장 전기저항 마찰교반 스폿용접장치 및 실험 18
3.1 전기저항 마찰교반 스폿용접장치 설계 18
3.2 전기저항 마찰교반 스폿용접장치 제작 20
3.2 전기저항 마찰교반 스폿용접 실험 및 고찰 24
3.3.1 실험 방법 및 조건 24
3.3.2 접합 전류조건 선행 실험 28
3.3.3 접합 강도 실험 33
3.3.4 실험 결과 및 고찰 36
제 4 장 결론 42
참 고 문 헌 44
- Degree
- Master
-
Appears in Collections:
- 대학원 > 기계공학과
